More Cable Seal Information
Stock Cable Seals — 5.0mm Diameter
CTPAT and ISO 17712:2013 Compliant High (H) Security Seals
| MS-C5.0-12K MS-C5.0B-12K |
MS-C5.0-36K | MS-C5.0-54K | MS-C5.0-76K MS-C5.0B-76K |
|
|---|---|---|---|---|
| Compliance Rating: | Meets ISO 17712 criteria for HIGH SECURITY Seal & Produced in CTPAT rated facility Click to View ISO 17712 Certificate of Conformance |
|||
| Cable Material: | Galvanized steel (silver), Non-preformed | |||
| Locking Type: | Adjustable length | |||
| Tensile Break Strength: | 3,498 lb (15.91 KN) | |||
| Locking Body: | Aluminum, Black (Blue for MS-C5.0B) | |||
| Stock Imprint (color): | SECURED, Unique serial number & 128 barcode (white) | |||
| Packaging: | Sold in bags of 10 seals | |||
| Cable Diameter & Length: | 5.0mm (0.196 in) x 12 in | 5.0mm (0.196 in) x 36 in | 5.0mm (0.196 in) x 54 in | 5.0mm (0.196 in) x 76 in |
| Overall Length: | 14 in | 38 in | 56 in | 78 in |
| Weight (Bag of 10 seals): | 1.4 lbs | 2.7 lbs | 3.7 lbs | 4.8 lbs |
| Full Case Quantity (weight): | 200 seals (28 lbs) | 100 seals (27 lbs) | 100 seals (37 lbs) | 100 seals (48 lbs) |
DualGuard™ Bolt Cable Seals — 5.0mm Diameter
CTPAT and ISO 17712:2013 Compliant High (H) Security Seals
| MS-C5B9-76KY | |
|---|---|
| Compliance Rating: | Meets ISO 17712 criteria for HIGH SECURITY Seal & Produced in CTPAT rated facility Click to View ISO 17712 Certificate of Conformance |
| Cable Material: | Galvanized steel (silver), Non-preformed |
| Locking Type: | Adjustable length |
| Tensile Break Strength: | 3498 lb (15.9 KN) |
| Locking Body: | Aluminum, Black |
| Stock Imprint (color): | SECURED, Unique serial number & 128 barcode (white) |
| Packaging: | Sold as individual seals |
| Cable Diameter & Length: | 5.0mm (0.196 in) x 76 in |
| Overall Length: | 76 in |
| Weight (Bag of 1 seal): | 0.65 lbs |
| Full Case Quantity (weight): | 50 seals (33 lbs) |
Stock Cable Seals — 3.5mm Diameter
CTPAT and ISO 17712:2013 Compliant High (H) Security Seals
| MS-C3.5-12B MS-C3.5B-12B |
MS-C3.5-36B | MS-C3.5-54B | |
|---|---|---|---|
| Compliance Rating: | Meets ISO 17712 criteria for HIGH SECURITY Seal & Produced in CTPAT rated facility Click to View ISO 17712 Certificate of Conformance |
||
| Type Cable: | Galvanized steel (silver), Adjustable length, Non-preformed | ||
| Tensile Break Strength: | 2706 lb (12.3 KN) | ||
| Locking Body: | Aluminum, Blue | ||
| Stock Imprint (color): | SECURED, Unique serial number — 128 barcode (white) | ||
| Packaging: | Sold in bags of 10 seals | ||
| Cable Diameter & Length: | 3.5mm (0.138 in) x 12 in | 3.5mm (0.138 in) x 36 in | 3.5mm (0.138 in) x 54 in |
| Overall Length: | 14 in | 38 in | 56 in |
| Weight (Bag of 10 seals): | 0.7 lbs | 1.3 lbs | 1.8 lbs |
| Full Case Quantity (Weight): | 500 seals (35 lbs) | 200 seals (26 lbs) | 200 seals (36 lbs) |
| Case Dimensions: | 11 in x 15 in x 6 in | 12 in x 14.5 in x 6.5 in | 13 in x 21.5 in x 5 in |
| MS-C3.5-14R-SS | |
|---|---|
| Compliance Rating: | Produced in CTPAT rated facility |
| Type Cable: | Stainless Steel (Silver), Adjustable length, Non-preformed |
| Tensile Break Strength: | 2706 lb (12.3 KN) |
| Locking Body: | Aluminum, Red |
| Stock Imprint (color): | SECURED + unique serial number + 128 barcode (white) |
| Packaging: | Sold in bags of 10 seals |
| Cable Diameter & Length: | 3.5mm (0.138 in) x 12 in |
| Overall Length: | 15.5 in |
| Weight (Bag of 10 seals): | 0.7 lbs |
| Full Case Quantity (weight): | 500 seals (35 lbs) |
TwinLock™ Cable Seals — 3.5mm Diameter
CTPAT and ISO 17712:2013 Compliant High (H) Security Seals
| MS-C3.5T-18B | |||
|---|---|---|---|
| Compliance Rating: | Meets ISO 17712 criteria for HIGH SECURITY Seal / Produced in CTPAT rated facility Click to View ISO 17712 Certificate of Conformance |
||
| Type Cable: | Galvanized Steel (silver), Adjustable length, Non-preformed | ||
| Tensile Break Strength: | 2706 lb (12.3 KN) | ||
| Locking Body: | Aluminum, Blue | ||
| Stock Imprint (color): | SECURED, Unique serial number & 128 barcode (white) | ||
| Packaging: | Sold in bags of 10 seals | ||
| Cable Diameter & Length: | 3.5mm (0.138 in) x 18 in | ||
| Overall Length: | 19.75 in | ||
| Weight (Bag of 10 seals): | 1 lbs | ||
| Full Case Quantity (Weight): | 250 seals (26 lbs) | ||
| Case Dimensions: | 12 in x 20 in x 6 in | ||
| Installation Guide | MS-C3.5T-18B Installation Guide | ||
GeminiGuard™ Cable Seals — 3.5mm Diameter
CTPAT and ISO 17712:2013 Compliant High (H) Security Seals
| MS-C3.5X-73K | |||
|---|---|---|---|
| Compliance Rating: | Meets ISO 17712 criteria for HIGH SECURITY Seal & Produced in CTPAT rated facility Click to View ISO 17712 Certificate of Conformance |
||
| Type Cable: | Galvanized Steel (silver), Adjustable length, Non-preformed | ||
| Tensile Break Strength: | 2,706 lb (12.3 KN) | ||
| Locking Body: | Aluminum, Black | ||
| Stock Imprint (color): | SECURED + unique serial number + 128 barcode (white) | ||
| Packaging: | Sold in bags of 10 seals | ||
| Cable Diameter & Length: | 3.5mm (0.138 in) x 36" (2) cable lengths | ||
| Overall Length: | 73.0 in | ||
| Weight (Bag of 10 seals): | 2.4 lbs | ||
| Full Case Quantity (Weight): | 100 seals (24 lbs) | ||
| Case Dimensions: | 11 in x 15-1/4 in x 6 in | ||
| Installation Guide | MS-C3.5X-73X Installation Guide | ||
Stock Cable Seals - 2.0mm diameter
| MS-C2.0-12R MS-C2.0-12B |
MS-C2.0-24R | MS-C2.0-36R | MS-C2.0-54R | |
|---|---|---|---|---|
| Compliance Rating: | Produced in CTPAT rated facility | |||
| Type Cable: | Galvanized Steel (silver), Adjustable length, Non-preformed | |||
| Tensile Break Strength: | 1,056 lb (4.8 KN) | |||
| Locking Body: | Aluminum, Red (Blue for MS-C2.0-12B) | |||
| Stock Imprint (color): | SECURED + unique serial number + 128 barcode (white) | |||
| Packaging: | Sold in bags of 10 seals | |||
| Cable Diameter & Length: | 2.0mm (0.079 in) x 12 in | 2.0mm (0.079 in) x 24 in | 2.0mm (0.079 in) x 36 in | 2.0mm (0.079 in) x 54 in |
| Overall Length: | 14 in | 26 in | 38 in | 56 in |
| Weight (Bag of 10 seals): | 0.3 lbs | 0.4 lbs | 0.6 lbs | 0.8 lbs |
| Full Case Quantity (weight): | 1000 seals (30 lbs) | 1000 seals (40 lbs) | 500 seals (28 lbs) | 500 seals (38 lbs) |
| MS-C2.0-12B-SS | |
|---|---|
| Compliance Rating: | Produced in CTPAT rated facility |
| Type Cable: | Stainless Steel (Silver), Adjustable length, Preformed |
| Tensile Break Strength: | 1,056 lb (4.8 KN) |
| Locking Body: | Aluminum, Blue |
| Stock Imprint (color): | SECURED + unique serial number + 128 barcode (white) |
| Packaging: | Sold in bags of 10 seals |
| Cable Diameter & Length: | 2.0mm (0.079 in) x 12 in |
| Overall Length: | 14 in |
| Weight (Bag of 10 seals): | 0.3 lbs |
| Full Case Quantity (weight): | 1000 seals (30 lbs) |
Stock Cable Seal — 1.8mm diameter
| MS-C1.8-48W | |
|---|---|
| Compliance Rating: | Produced in CTPAT rated facility |
| Type Cable: | Galvanized steel (silver), Fixed length, Non-preformed |
| Locking Body: | Plastic (ABS), white |
| Stock Imprint (color): | Unique serial number (black) |
| Packaging: | Sold in bags of 10 seals |
| Cable Diameter & Length: | 2.0mm (0.079 in) x 48 in |
| Overall Length: | 50 in |
| Weight (Bag of 10 seals): | 0.7 lbs |
| Full Case Quantity (weight): | 500 seals (35 lbs) |
Stock Cable Seals - 1.5mm Diameter
| MS-C1.5-12G | MS-C1.5-36G | MS-C1.5-54G | |
|---|---|---|---|
| Compliance Rating: | Produced in CTPAT rated facility | ||
| Type Cable: | Galvanized steel (silver), Adjustable length, Non-preformed | ||
| Tensile Break Strength: | 704 lb (3.2 KN) | ||
| Locking Body: | Aluminum, Green | ||
| Stock Imprint: | SECURED, unique serial number & 128 barcode (white) | ||
| Packaging: | Sold in bags of 10 seals | ||
| Cable Diameter & Length: | 1.5mm (0.059 in) x 12 in | 1.5mm (0.059 in) x 36 in | 1.5mm (0.059 in) x 54 in |
| Overall Length: | 14 in | 38 in | 56 in |
| Weight (Bag of 10 seals): | 0.3 lbs | 0.4 lbs | 0.5 lbs |
| Full Case Quantity (weight): | 1000 seals (30 lbs) | 1000 seals (40 lbs) | 1000 seals (50 lbs) |
| MS-C1.5-36R | |
|---|---|
| Compliance Rating: | Produced in CTPAT rated facility |
| Type Cable: | Galvanized Steel (silver), Adjustable length, Non-preformed |
| Tensile Break Strength: | 704 lb (3.2 KN) |
| Locking Body: | Aluminum, Red |
| Stock Imprint (color): | SECURED, Unique serial number & 128 barcode (white) |
| Packaging: | Sold in bags of 10 seals |
| Cable Diameter & Length: | 1.5mm (0.059 in) x 36 in |
| Overall Length: | 38 in |
| Weight (Bag of 10 seals): | 0.4 lbs |
| Full Case Quantity (weight): | 1000 seals (40 lbs) |
| MS-C1.5-18K-SS | |
|---|---|
| Compliance Rating: | Produced in CTPAT rated facility |
| Type Cable: | Stainless Steel (Silver), Adjustable length, Non-preformed |
| Tensile Break Strength: | 704 lb (3.2 KN) |
| Locking Body: | Aluminum, Black |
| Stock Imprint (color): | SECURED, Unique serial number — 128 barcode (white) |
| Packaging: | Sold in bags of 10 seals |
| Cable Diameter & Length: | 1.5mm (0.059 in) x 18 in |
| Overall Length: | 20 in |
| Weight (Bag of 10 seals): | 0.4 lbs |
| Full Case Quantity (weight): | 1000 seals (40 lbs) |
Navaloop Bolt Cable Seals — 1.8mm diameter
| MS-BC-03 | |
|---|---|
| Compliance Rating: | Produced in CTPAT rated facility |
| Color: | white with black imprint |
| Cable: | Galvanized steel (silver) 48 in length, 1.8mm diameter (0.7 in), Non-preformed |
| Bolt: | 7mm diameter steel bolt; 9.5mm overall with plastic covering |
| Bolt Head Dimensions: | 16.5mm (0.65 in) x 31.2mm (1.23 in) x 8.2mm (0.32 in) |
| Lock Dimensions: | 19.6mm diameter (0.7715 in) x 48.5mm height (1.9 in) |
| Packaging | Sold In Bag of 10 Seals |
| Cable Locking Type: | Fixed length |
| Tensile Break Strength: | 970 lbs. |
| Stock Imprint: | Unique Serial Number & "NAVATECH" Brand name in black ink |
| Weight: | 1.8 lbs |
| Full Case Quantity: | 100 seals |
| Case Dimensions: | Length: 16 in (406.4mm) Width: 9 in (228.6mm) Height: 6 in (152.4mm) |
| Case Weight: | 18 lbs |
